Application
5-7
The source can use Shift Up/Shift Down to choose the desired measurement.
If the AC Source is in output state, press OUT/QUIT the output will quit waveform to zero
voltage. If press OUT/QUIT again, the AC Source only outputs the waveform set in MAIN
PAGE. Users must press ENTER to trigger it again. If in quit state, users can press ENTER
to output PULSE waveform directly.
The pulse wave will shut down when PAGE/EXIT is pressed to exit PULSE execution page.
PULSE mode example:
_TRIG_OFF * RUNNING * [ PULSE ]
F Φ1 = 0.00 Φ2 = 0.00 Φ3 = 0.00
P Φ1 = 0.000 Φ2 = 0.000 Φ3 = 0.000
_TRIG_OFF * RUNNING * [ PULSE ]
PF Φ1 = 0.00 Φ2 = 0.00 Φ3 = 0.00
CF Φ1 = 0.000 Φ2 = 0.000 Φ3 = 0.000
Vac = 100.0 F = 50.00 Vdc= 0.0
DUTY = 35.0 % PERIOD = 100.0 ms
<SHIFT> <ENTER> to Execute
TRIG= AUTO WAVE
A [PULSE]
DEGREE_Φ1= 0.0
<SHIFT> <ENTER> to Execute
