Application
5-9
COUNT: the number of each change execution.
DWELL: the length of each step.
Vac, F, Vdc: the initial value of Vac, F, DC when STEP mode starts to execute.
dV, dF, dDC: the difference value of each step. (The negative value is allowed.)
TRIG = AUTO/MANUAL: the way to trigger. AUTO: It will finish all COUNT number when
triggered. MANUAL: The output waveform will change one step for each execution.
WAVE = A/B: the waveform selection (see 3.6.2).
DEGREE:
the output phase angle of each step.
Press SHIFT and ENTER to go to STEP execution page. The LCD shows _TRIG_ON is
under action, and * STOP * is the triggering state at present. Press ENTER to trigger it.
Then LCD shows * RUNNING * and TRIG_OFF and TRIG_PAUSE. Press or to move
the cursor and press ENTER to select it. TRIG_OFF is to stop the STEP waveform from
changing. TRIG_PAUSE is to keep the STEP waveform until TRIG_CONTINUE is selected.
The LCD shows * STOP * when the AC Source executed all COUNT.
The source can use Shift Up/Shift Down to choose the desired measurement.
TRIG= AUTO WAVE = A [STEP]
DEGREE_Φ1 = 0.0
<SHIFT> <ENTER> to Execute
_TRIG_ON * STOP * [ STEP ]
Vrms
Φ1 = 0.00 Φ2 = 0.00 Φ3 = 0.00
I rms
Φ1 = 0.00 Φ2 = 0.00 Φ3 = 0.00
_TRIG_OFF * RUNNING * [ STEP ]
TRIG_PAUSE
Vrms
Φ1 = 0.00 Φ2 = 0.00 Φ3 = 0.00
I rms
Φ1 = 0.00 Φ2 = 0.00 Φ3 = 0.00
_TRIG_OFF * PAUSE * [ STEP ]
TRIG_CONTINUE
Vrms
Φ1 = 0.00 Φ2 = 0.00 Φ3 = 0.00
I rms
Φ1 = 0.00 Φ2 = 0.00 Φ3 = 0.00
