Programmable AC Source 61705 User’s Manual
5-10
If the AC Source is in output state, press OUT/QUIT the output will quit waveform to zero
voltage. If press OUT/QUIT again, the AC Source only outputs the waveform set in MAIN
PAGE. Users must press ENTER to trigger it again. If in quit state, users can press ENTER
to output STEP waveform directly.
The STEP wave will stop executing when PAGE/EXIT is pressed to exit STEP execution page.
When TRIG = MANUAL, the LCD shows TRIG_UP and TRIG_DOWN. The output waveform
will change to the next step if TRIG_UP is selected. If TRIG_DOWN is selected the output
waveform will change back to the last step.
STEP mode example:
_TRIG_OFF * RUNNING * [ STEP ]
TRIG_PAUSE
F
Φ1 = 0.00 Φ2 = 0.00 Φ3 = 0.00
P
Φ1 = 0.00 Φ2 = 0.00 Φ3 = 0.00
_TRIG_UP * STOP * [ STEP ]
TRIG_DOWN
Vrms
Φ1 = 0.00 Φ2 = 0.00 Φ3 = 0.00
I rms
Φ1 = 0.00 Φ2 = 0.00 Φ3 = 0.00
_TRIG_OFF * RUNNING * [ STEP ]
TRIG_PAUSE
PF Φ1 = 0.00 Φ2 = 0.00 Φ3 = 0.00
CF Φ1 = 0.00 Φ2 = 0.00 Φ3 = 0.00
COUNT = 3 DWELL = 60.0 ms [ STEP ]
Vac = 40.0 F = 50.00 Vdc = 0.0
dV = 10.0 dF = 50.00 dDC = 20.0
<SHIFT> <ENTER> to Execute
TRIG= AUTO WAVE = A [STEP]
DEGREE_Φ1 = 0.0
<SHIFT> <ENTER> to Execute ▲
To Next Page
