TEST ACTION APPLICABILITY
5 Turn the ignition off.
Disconnect the O2 Sensor harness connector.
Ignition on, engine not running.
With the DRBIIIt, monitor the O2 Sensor voltage.
Is the voltage above 4.8 volts?
All
Yes → Go To 6
No → Check the O2 Signal circuit for a short to ground, open, or short
to voltage. Inspect the O2 Sensor connector and the PCM harness
connector. If OK, replace and program the Powertrain Control
Module in accordance with the Service Information.
Perform POWERTRAIN VERIFICATION TEST VER-5-NGC.
6 Turn the ignition off.
Disconnect the O2 Sensor harness connector.
Ignition on, engine not running.
Measure the voltage on the O2 Return circuit in the O2 Sensor harness connector.
Is the voltage at 2.5 volts?
All
Yes → Check the fuel system for contaminants.
Perform POWERTRAIN VERIFICATION TEST VER-5-NGC.
No → Check the O2 Return circuit for a short to ground, open, or short
to voltage. Inspect the O2 Sensor connector and the PCM harness
connector. If OK, replace and program the Powertrain Control
Module in accordance with the Service Information.
Perform POWERTRAIN VERIFICATION TEST VER-5-NGC.
279
DRIVEABILITY - NGC
P2096-DOWN STREAM FUEL SYSTEM 1/2 LEAN — Continued
