English
31 EN
9) Remove the ZKHHOIDVWHQLQJSLQ on the side (L) and
remove the moving mechanisms inside the hopper;
10) Turn the IDVWHQLQJULQg (M) at the rear of the hopper
clockwise and remove the GLVSHQVLQJVFUHZXQLW(Q);
11) Remove the worm screw (K) from the
(R);
12) Remove the solubles chute unit (S) turning it clockwise
LQFRQ¿JXUDWLRQVZLWKDGRXEOHFKXWHUHPRYHWKHXQLW
RQWKHOHIW¿UVW
13) Separate the solubles chute unit (S), lightly lifting it in
the indicated point.
Remove any soluble product remaining in the hopper.
Use a damp cloth to clean the hopper with products suitable
for objects that come in contact with foodstuffs. Carefully
rinse and dry, and remove any organic residues.
Before repositioning all the parts previously removed, make
sure all the wet or damp parts have been perfectly dried.
