English
30 EN
SOLUBLES HOPPER CLEANING (6b), where present
The solubles hopper (6b) must be periodically cleaned (every
week, approximately). Depending on consumption and type
of product, cleaning can be performed more frequently.
The images opposite are that of a double solubles hopper.
Please follow these steps:
1) Open the lock (A);
2) Open the control panel (B);
3) Push the hopper closing device (Hs) towards the back
of the machine;
4) Open the hopper lock (Ts) and remove the cover (Cs);
5) Use a tool to turn the fastening device (Fs) counter-
clockwise;
6) Move the hopper towards the front of the machine;
7) Slightly raise the rear of the hopper and remove the
solubles hopper (6b) from the machine;
8) Remove the 2 wheel stop (P);
open
closed
12. Cleaning operations
Level 2
