117
Update
Chapter 4
Changing Symbology Settings
4.6 CODE 93
You can only confi
gure the scanner to read this symbology
or not.
4.7 CODE 128
You can only confi
gure the scanner to read this symbology
or not.
*Enable Code 93
D
isable Code 93
*Enable Code 128
D
isable Code 128
128
130
