Appendix III
Keyboard Wedge Table
EXAMPLE
KEY TYPE = NORMAL
For example, if you want to program the character “!” as the prefix code:
1. Read the “Configure Prefix” label.
2. Read the “Hexadecimal Value” label on page 206 for “2” and “1”.
3. Read the “Validate” label to complete this setting.
KEY TYPE = SCAN CODE
For example, if you want to program the character “a” (= “1C” on the scan code table) as the
prefix code:
1. Read the “Configure Prefix” label.
2. Read the “Scan Code” label.
3. Read the “Hexadecimal Value” label on page 206 for “1” and “C”.
4. Read the “Validate” label to complete this setting.
KEY TYPE = NORMAL + KEY STATUS = SHIFT
For example, if you want to program the character “!” (= “Shift” + “1” on keyboard) as the prefix
code:
1. Read the “Configure Prefix” label.
2. Read the “Add Shift” label.
3. Read the “Hexadecimal Value” label on page 206 for “3” and “1”.
4. Read the “Validate” label to complete this setting.
