181
Update
Chapter 6
Applying Formats for Data Editin
6.5 CONFIGURING FORMAT — DEFINE TRANSMISSION SEQUENCE
After configuring the data fields and additional fields, you must now program the
transmission sequence of these fields that comprise the final data. This field transmission
sequence can be assigned in any desired order and fields can be assigned multiple times
as well.
Note: Up to twelve fields can be assigned.
1) Read the “Start” label to begin with programming the field transmission sequence.
2) Program the transmission sequence by reading the desired fields as well as additional
fields.
Start (Programming) …
Field 1 Field 2
Field 3 Field 4
Field 5 Field 6
Additional Field 1
dditional Field 2
Additional Field 3
dditional Field 4
Additional Field 5
To Next Page
