176
End Programming Format
1560 Series Barcode Scanner User Guide
Field 2 Setting
1. Read the above label to divide field by a specified terminating string.
2. Read the “Hexadecimal Value” label on page 206 for the desired character string.
3. Read the “Validate” label to complete this setting.
4. Read the “Discard Separator” label if the field separator is not desired in the field.
If not dividing the field by a specific separator, you may divide it by a specified length.
1. Read the above label to divide field by length.
2. Read the “Decimal Value” label on page 205 for the desired field length.
3. Read the “Validate” label on the same page to complete this setting.
Select Field Separator
to Divide Field 2 …
*Include Separator
scard Separator
Divide Field 2 by Length …
To Next Page
