STREAM Wireless Studio User Guide
Trim Spaces To make the most use of the mobile computer screen, unnecessary spaces may
be discarded. Select the check box to enable this feature.
Note that spaces between characters will not be discarded.
Original line:
-> 1. Set up<-
Trimmed:
->1. Set up<-
Remove
Empty Line
(for 5250
only)
Select the check box to automatically ignore empty lines on the host screen.
Note that this feature can only be enabled when there is no contradiction
with 5250's field definition
Login Hot Key
User Name
Password
By default, the shortcut keys are disabled. That is, you need to enter
username/password manually.
Select the shortcut keys (FN+0 ~ FN+9) so that you can enter the text
string for Username/Password by two strokes. The selected key
combinations will become unavailable on the Function Key Mapping list. For
example, if you select FN+0 for “Username” and FN+1 for “Password”, you
will find them mapped to “Name Key” and “Password Key” individually in the
Function Key Mapping of the Emulation tab.
Enable Scanner
Always enable By default, the barcode reader is enabled. However, you may send an escape
sequence to control it.
Controlled by
ESC (or 5250)
commands
If selected, the barcode reader is disabled after login. It will not work until
you send the specific ESC or 5250 command to enable it.
VT Emulation
Enable You may specify an ESC command other than the default
“ESC[2;1]”.
Disable You may specify an ESC command other than the default
“ESC[2;0]”.
Enable RFID Reader
Always enable By default, the RFID reader is enabled.
The RFID reader co-exists with the barcode reader, which is also called "dual
mode" because both readers can work at the same time.
Controlled by
ESC (or 5250)
commands
If selected, the RFID reader is disabled after login. It will not work until you send
the specific ESC or 5250 command to enable it.
VT Emulation
Enable You may specify an ESC command other than the default
“ESC[3;1]”.
Disable You may specify an ESC command other than the default
“ESC[3;0]”.
