33
2) Connect the adapter to the Cradle, and plug the other end into an electrical outlet.
The status of the mobile computer charging is shown on the device itself, while the LED
indicator on RS31 Charging Cradle shows the status of battery charging as below:
Note:
(1) Not Charging could be the result of battery damage, battery’s failure to touch the
connector, or AC plug coming off.
(2) Charging error could be due to high battery temperature.
Charging Red, solid Charging the battery
Red, blink Charging error
Green, solid Charging complete
No light Not charging
