Wibeee

Instruction Manual

Figure 42: HPPT queries: Device ID�

5�4�1�2�- Values of the device's variables

To view the values of all of the device's variables, use the following request:

http://ip_address/services/user/values.xml?id=device

Itisalsopossibletoviewspecicvariables,seeTable 11 with the available variables.

http://ip_address/services/user/values.xml?var=device.variable

Figure 43:HPPT queries: Values of the device's variables�

Table 11: Variables table�

Variable Description Units

<var>measuresRefresh</var> Measures refresh time of the internal web Seconds

<var>appRefresh</var> Time sending data to the server. Minutes

<var>softVersion</var> Firmware version of the device -

<var>model</var> Modelidentier -

<var>ipAddr</var> Type of IP : DHCP or static IP -

<var>gwAddr</var> The device's current IP. -

<var>subnetMask</var> Gateway. -

Circutor WIBEEE Series User Manual
