Instruction Manual
Wibeee
Table 11 (Cont�): Variables table
Variable Description Units
<var>primaryDNS</var> Primary DNS server. -
<var>secondaryDNS</var> Secondary DNS server. -
<var>macAddr</var> MACidentier -
<var>ssid</var> Name of the network. -
<var>keyEnc</var> Password type. -
<var>keyType</var> Password format: Hex or ASCII -
<var>securKey</var> Password. -
<var>serverIp</var> Name of the server domain. -
<var>serverIpResolved</var> IP address of the server. -
<var>serverPort</var> Sending port. -
<var>vrms1</var> Phase voltage L1 V
<var>vrms2</var> Phase voltage L2 V
<var>vrms3</var> Phase voltage L3 V
<var>vrmst</var> Total voltage (average of L1, L2, L3) V
<var>irms1</var> Current L1 A
<var>irms2</var> Current L2 A
<var>irms3</var> Current L3 A
<var>irmst</var> Total current (average of L1, L2, L3) A
<var>pap1</var> Apparent Power L1 VA
<var>pap2</var> Apparent Power L2 VA
<var>pap3</var> Apparent Power L3 VA
<var>papt</var> Total Apparent Power VA
<var>pac1</var> Active Power L1 W
<var>pac2</var> Active Power L2 W
<var>pac3</var> Active Power L3 W
<var>pact</var> Total Active Power W
<var>preac1</var> L1 Reactive Power Var
<var>preac2</var> L2 Reactive Power Var
<var>preac3</var> L3 Reactive Power Var
<var>preact</var> Total Reactive Power Var
<var>freq1</var> Frequency L1 Hz
<var>freq2</var> Frequency L2 Hz
<var>freq3</var> Frequency L3 Hz
<var>freqt</var> Total frequency (average of L1, L2, L3) Hz
<var>fpot1</var> Power Factor L1 -
<var>fpot2</var> Power Factor L2 -
<var>fpot3</var> Power Factor L3 -
<var>fpott</var> Total Power Factor -
<var>eac1</var> Active Energy L1 Wh
<var>eac2</var> Active Energy L2 Wh
<var>eac3</var> Active Energy L3 Wh
<var>eactt</var> Total Active Energy Wh
<var>ereactl1</var> Inductive Reactive Energy L1 VArLh
<var>ereactl2</var> Inductive Reactive Energy L2 VArLh
