Cisco 1552S - Console Connector

1-10
Cisco Aironet 1552 Series for Hazardous Locations Installation Guide
Chapter 1 Overview
Hardware Features
Console Connector
Figure 1-4 Console Port for Access Point Model AIR-CAP1552H-x-K9 and
AIR-CAP1552SA/SD-x-K9
Figure 1-5 Console Port for Access Point Model AIR-CAP1552WU-x-K9
1 Console port 2 Not used on the H model, Fiber port on the S
model. (5/8-24UNEF-2B)
282138
1 2
1 Console port (internal on the 1552WU)
