Cisco 1552S - Layer 3 Network Operation

1-28
Cisco Aironet 1552 Series for Hazardous Locations Installation Guide
Chapter 1 Overview
Hardware Features
Layer 3 Network Operation
The access points support Layer 3 network operation. Access points and controllers in Layer 3
configurations use IP addresses and UDP packets, which can be routed through large networks. Layer 3
operation is scalable and recommended by Cisco.
Figure 1-18 illustrates a typical Layer-3 wireless network configuration containing access points and a
controller.
Figure 1-18 Typical Layer 3 Access Point Network Configuration Example
148458
