3-77
Cisco Aironet 1552 Series for Hazardous Locations Installation Guide
Chapter 3 Installing the 1552 Series Access Points in Hazardous Locations
Powering the Access Point
Step 7 Check your work.
Step 8 Close the access point hinged cover. See the “Closing the Access Point Hinged Cover” section on
page 3-59 for details.
Connecting Ground and AC Power
Note When you install the conduit, be sure to comply with the local electrical codes for your area.
Refer to “Table D-2Power Consumption Budget for the AIR-CAP1552H-x-K9,
AIR-CAP1552SA/SD-x-K9, and AIR-CAP1552WU-A-K9 Access Point Configurations” section on
page D-22 for Power distribution details.
To route and connect the ground and AC power cabling to the 1552H or 1552SA access point model,
follow these steps:
Warning When installing or replacing the unit, the ground connection must always be made first and
disconnected last. Statement 1046
Caution Always install the ground wire before connecting all power leads.
Step 1 Open the access point hinged cover. See the “Opening the Access Point Hinged Cover” section on
page 3-58 for instructions.
Step 2 Use a Phillips head screwdriver to loosen the three captive screws that secure the AC entry module cover.
(Figure 3-24).
