1-16
Cisco Aironet 1552 Series for Hazardous Locations Installation Guide
Chapter 1 Overview
Hardware Features
Figure 1-10 Cisco Aironet Dual-Band Omnidirectional Antenna - Installed on Model
AIR-CAP1552H-x-K9
1
Antenna connected to antenna port 4 (Type N connector) (Wi-Fi TX/RX)
2
Antenna connected to antenna port 5 (Type N connector) (Wi-Fi RX)
3
Antenna connected to antenna port 6 (Type N connector) (Wi-Fi TX/RX)
1
2
3
282145
