3-47
Cisco Aironet 1552 Series for Hazardous Locations Installation Guide
Chapter 3 Installing the 1552 Series Access Points in Hazardous Locations
Mounting on a Wall or a Pole
Caution The mounting surface, attaching screws, and optional wall anchors must be able to support a 50-lb
(22.7 kg) static weight.
Table 3-1 Material Needed to Mount Access Point to a Vertical Wall
Materials Required In Kit
•
Ground lug and screws (provided with access point)
• Crimping tool for ground lug, Panduit CT-720 with
CD-720-1 die (http://onlinecatalog.panduit.com)
• Four M8 or 5/16 in. (31 mm) screws
• Four wall anchors (specified for wall material)
• Drill bit for wall anchors
• Electric drill and standard screwdriver
• #6-AWG ground wire
• Shielded outdoor-rated Ethernet (CAT5e or better) cable
• Grounding block
• Grounding rod
• 13-mm box-end wrench or socket set
Yes
No
No
No
No
No
No
No
No
No
No
