7-31
Cisco TelePresence System 3200
OL-14521-01
Chapter 7 Building the Second Row Table Assembly
Parts List
Figure 7-29 Gutter Panel Reinforcement Screws
Step 30 Attach the panel end brace to the table leg and left tabletop end and attach the table leg to the tabletop
and tabletop end.
204182
35
35
35
35
