Cisco 3200 - Carton 51 of 58: Display Shelf Supports and Codec Tray, 69-1626-XX, CTS3 K-STRUCTURE

A-18
Cisco TelePresence System 3200
OL-14521-01
Appendix A Appendix A: Parts List Sorted by Carton
Carton 51 of 58: Display Shelf Supports and Codec Tray, 69-1626-xx, CTS3K-STRUCTURE
Carton 51 of 58: Display Shelf Supports and Codec Tray,
69-1626-xx, CTS3K-STRUCTURE
Carton 52 of 58: Tabletop Leg Base, 69-1620-xx,
CTS3K-STRUCTURE
Carton 53 of 58: Tabletop Leg Base, 69-1914-xx,
CTS3K-STRUCTURE
700-27312-01 Cable Cover for right end privacy panel 1
700-27413-01 Tabletop end brace 2
69-1635-xx Table leg screws 4
48-1641-01 M4 x 12mm flat head screws 6
48-2426-01 M4.0x10mm pan head screws 2
700-23305-01 I/O Module Cover plate 1
55-3869-01 PKG,DST,LID,WOOD SPKR PANL,JW3 1
Kit ID Number
Sub-Kit ID
Number
Part Number Part Description Qty
Chapter Parts List
Reference
69-1626-xx 700-23339-xx Display shelf support left 3 Chapter 2
700-23340-xx Display shelf support right 3 Chapter 2
700-23341-xx Codec safety tray 3 Chapter 2
Kit ID Number
Sub-Kit ID
Number
Part Number Part Description Qty
Chapter Parts List
Reference
69-1620-xx 69-1636-xx 700-23305-01 I/O Module Cover plate 4 Chapter 7
800-28454-xx Tabletop leg base 3 Chapter 6
800-28628-xx Tabletop leg base, left 1 Chapter 6
Kit ID Number
Sub-Kit ID
Number
Part Number Part Description Qty
Chapter Parts List
Reference
69-1620-xx 69-1636-xx 700-23305-01 I/O Module Cover plate 4 Chapter 7
800-28454-xx Tabletop leg base 4 Chapter 6
Kit ID Number
Subkit ID
Number Part Number Part Description Qty
Chapter Parts
List Reference
