Chapter 12 Field-Replaceable Unit Guide
Replacing a Plasma Display—Part Number CTS-DISP-65-GEN4=
• * Safety glasses
• * Box cutters
Cisco TelePresence 3200 Structure, Accessory, and Adjustment Assembly:
• Power screwdriver with 2.5, 3, and 6 mm (standard or round) Allen bits, or standard 2.5, 3, and 6 mm
Allen wrenches
Tip A round-head Allen bit allows the bit to work at an angle instead of only straight out, which is
helpful in tight spots.
• Manual screwdrivers, Phillips and flat head types
• Metric wrenches, 10 to 15 mm
• 9/64-inch Allen wrench (supplied with speakers)
• 0.9mm Allen wrench for camera lens adjustments (if the lens uses a thumbscrew no tools are
required)
• Level
• Masking tape
• * Tie wraps
• Laptop computer attached to network
• * Step ladder
* Recommended for best results
Removing Audio Components
Caution Take care not to mar or introduce smudges or dirt to the surface of the projector screen.
Step 1 Power off the system by completing turning off the following units:
• The two left PDUs on the left accessory cabinet
• The single right PDU on the right accessory cabinet
• The auxiliary control unit on the center display structure
Caution Make sure all system power is turned off before beginning this disassembly.
Step 2 Remove the Projector screen by performing one of the following actions:
• If your projector screen is slightly recessed and uses black side trims, complete the following steps:
a. Remove the side trims from the edges of the display.
Be careful not to mar the screen when you perform this step.
b. Use an open-ended wrench to loosen the feet on the bottom of the screen, and lower the screen.
