Cisco 3200 - Chapter 7 Building the Second Row Table Assembly; Parts List

7-2
Cisco TelePresence System 3200
OL-14521-01
Chapter 7 Building the Second Row Table Assembly
Parts List
5
Gutter and privacy panel support bracket,
type 2
700-27279-xx 5 50
6
Gutter panel, section 1 (section 5) 800-31126-xx 1 50
7
Gutter panel, section 2 (section 4) 800-31129-xx 1 50
8
Gutter panel, section 3 (section 6) 800-31131-xx 1 50
9
Gutter panel, section 4 (section 3) 800-31133-xx 1 50
10
Gutter panel, section 5 (sections 2 and 7) 800-31124-xx 2 50
11
Privacy panel hanger 700-27311-xx 14 50
12
Floating bracket, type 1 700-27282-xx 2 50
13
Floating bracket, type 2 700-27281-xx 2 50
14
Tabletop: section 1 (section 5) 95-9995-01
Kit # 74-5565-01
1 26
15
Tabletop: section 2 (section 4) 95-10096-01
Kit # 74-5600-01
1 26
16
Tabletop: section 3 (section 6) 95-10097-01
Kit # 74-5601-01
1 26
17
Tabletop: section 4 (section 3) 95-10098-01
Kit # 74-5602-01
1 26
18
Tabletop: section 5 (sections 2 and 7) 95-9994-01
Kit # 74-5562
2 26 Some tabletop sections are marked
“5
left” and “5 right”; install the sections
so that the tabletop grain is correctly
matched.
19
Tabletop end, left (section 6) 95-10099-01
Kit # 74-5603-01
1 26
20
Tabletop end, right (section 7) 95-10100-01
Kit # 74-5604
1 26
21
Tabletop end brace 700-27413-xx 2 50
22
Privacy panel alignment bracket,
section
1 (section 5)
700-27275-xx 1 50
23
Privacy panel alignment bracket,
section
2 (section 4)
700-27276-xx 1 50
24
Privacy panel alignment bracket,
section
3 (section 6)
700-27277-xx 1 50
25
Privacy panel alignment bracket,
section
4 (section 3)
700-27278-xx 1 50
26
Privacy panel alignment bracket,
section
5 (sections 2 and 7)
700-27274-xx 2 50
27
Privacy panel, section 1 (section 5) 800-31112-xx 1 50
28
Privacy panel, section 2 (section 4) 800-31116-xx 1 50
29
Privacy panel, section 3 (section 6) 800-31117-xx 1 50
30
Privacy panel, section 4 (section 3) 800-31119-xx 1 50
Key Part Description Part Number Qty Ctn Notes
