7-3
Cisco TelePresence System 3200
OL-14521-01
Chapter 7 Building the Second Row Table Assembly
Parts List
31
Privacy panel, section 5 (sections 2
and
7)
800-31121-xx 2 50
32
Privacy Panel, left end section 6
(section
8)
800-31123-xx 1 50
33
Privacy Panel, right end section 7
(section 1)
800-31122-xx 1 50
34
Tabletop attachment plate, metal 700-27292-xx 2 50
35
M8 x 16 mm screws 48-2430-01 58 21
36
M8 x 2.5mm shoulder screws 69-1880-01
48-2437-01
30 21
37
M8 x 16 mm screws 48-2430-01 24 21
38
Screw, 8 x 50 mm, with plastic knob 69-1877-01
48-2298-01
15 21
39
Draw bolt No part number 14 1
40
Spline No part number 5 1 Either splines or wooden biscuits (callout
number 57) are supplied with the table
sections; use either the splines or the
biscuits to join the table sections.
41
Cable Cover for right end privacy panel 700-27312-01 1 50
42
Velcro attachments for cable guide No part number 2 Included with cable cover
43
I/O blank: large 700-23806-01 2 1
44
I/O blank: small 700-23807-01 14 1
45
I/O modules: power/Ethernet 74-xxxx-xx 12 1 Part number changes per country. Refer
to
“Appendix B: Region- and
Country-Specific Equipment” for part
number.
46
I/O Module Cover plate 700-23305-01 7 50-
54
47
Cat6 Ethernet cord 37-0887-02 (3M)
37-0901-01 (10M)
37-0965-01 (12M)
1
8
3
1
48
3 m Jumper cord 37-0833-01 9 1
49
M4 nuts 49-0326 20 1
50
M4 x 12 mm screws, black 48-2426-01 10 1
51
Microphone 74-4743-01 6 1
52
M4 x 30 mm screws 1 Included in Microphone kit.
53
M4 washers 1 Included in Microphone kit.
54
Power distribution units 74-4787-01 2 1 Chapter 7, 8
55
Screws To be prov ided 1 1
56
M8 shoulder screws for Floating
Brackets
69-1880-01
48-2437-01
28 21
Key Part Description Part Number Qty Ctn Notes
