Cisco TelePresence System 3200
OL-14521-01
2
Building the Display Assembly
Revised: February 10, 2010, OL-14521-01
Parts List
Key Part Description Part Number Qty Ctn Notes
1
Display structure 700-23358-xx 3 35,
36,
37
2
Rear foot stabilizer 700-23360-xx
Kit# 69-1625-xx
6 18
3
Front foot stabilizer 700-23359-xx
Kit # 69-1624-xx
6 15,
16,
17
4
Leveling foot 51-4540-xx
Kit # 69-1654-xx
12 1
5
Display shelf support left 700-23339-xx
Kit # 69-1626-xx
51 45
6
Display shelf support right 700-23340-xx
Kit # 69-1626-01
51 45
7
Display tilt bracket 700-23363-xx 6 13
8
Codec safety tray 700-23341-xx
Kit # 69-1626-xx
3 51 If you are installing a presentation codec, use the
double-wide codec tray part no. 700-25301-01
for the center display assembly.
9
Camera assembly bracket 700-23346-xx
Kit # 69-1627-xx
1 12 For center display structure only
10
Support crossbars 700-23361-xx
Kit # 69-1623-xx
4 33
11
M8 x 70 mm screws 48-2274-01 1
12
M8 washers 49-1165-01 1
13
M8 x 20 mm screws 48-2273-01 1
