Cisco 3200 - Carton 50 of 58: Cisco Telepresence 3200 Structure-Addition to Standard CTS

A-17
Cisco TelePresence System 3200
OL-14521-01
Appendix A Appendix A: Parts List Sorted by Carton
Carton 50 of 58: Cisco TelePresence 3200 Structure—Addition to Standard CTS-3000, CTS32-STRUCTURE, 69-1854-01
Carton 50 of 58: Cisco TelePresence 3200 Structure—Addition to
Standard CTS-3000, CTS32-STRUCTURE, 69-1854-01
48-2285-01 M8 x 12 mm flat-head screws 10 Chapter 4
49-1165-01 M8 washers 10 Chapter 4
48-2433-01 M8 x 20 mm flat head screw, white 10 Chapter 4
69-1657-xx 48-2273-01 M8 x 20 mm screws 50 Chapter 7
Kit ID Number
Subkit ID
Number
Part Number Part Description Qty
Chapter Parts
List Reference
69-1854-01 MECHKIT,STRUCTURE,REAR TABLE,CTS32K
800-31112-01 Privacy panel, section 1 1
800-31116-01 Privacy panel, section 2 1
800-31117-01 Privacy panel, section 3 1
800-31119-01 Privacy panel, section 4 1
800-31121-01 Privacy panel, section 5 2
800-31122-01 Privacy Panel, right end (section 7) 1
800-31123-01 Privacy Panel, left end (section 6) 1
700-27273-01 FABMTL,STMP,PLT,END ALIGNMENT,32K 2
700-27274-01 Privacy panel support alignment bracket, section 5 2
700-27275-01 Privacy panel support alignment bracket, section 1 1
700-27276-01 Privacy panel support alignment bracket, section 2 1
700-27277-01 Privacy panel support alignment bracket, section 3 1
700-27278-01 Privacy panel support alignment bracket, section 4 1
700-27279-01 Gutter support bracket, type 2 5
700-27280-01 Gutter support bracket, type 1 2
700-27281-01 Floating bracket, type 2 5
700-27282-01 Floating bracket, type 1 2
800-31124-01 Gutter panel, section 5 2
800-31126-01 Gutter panel, section 1 1
800-31129-01 Gutter panel, section 2 1
800-31131-01 Gutter panel, section 3 1
800-31133-01 Gutter panel, section 4 1
700-27292-01 Tabletop attachment plate, metal 2
700-27311-01 Privacy Panel Hangers 12
Kit ID Number
Sub-Kit ID
Number Part Number Part Description Qty
Chapter Parts List
Reference
