A-16
Cisco TelePresence System 3200
OL-14521-01
Appendix A Appendix A: Parts List Sorted by Carton
Carton 48 of 44: Accessory Cabinet, Right, 69-1837-xx, CTS3K-FUR-MAPLE
Carton 48 of 44: Accessory Cabinet, Right, 69-1837-xx,
CTS3K-FUR-MAPLE
Carton 49 of 58: Lighting Assembly, 69-1612-xx,
CTS3K-LIGHT-STR
Kit ID Number
Sub-Kit ID
Number
Part Number Part Description Qty
Chapter Parts List
Reference
69-1837-xx 700-29441-01 Accessory cabinet, right 1 Chapter 5, 6
Kit ID Number
Sub-Kit ID
Number
Part Number Part Description Qty
Chapter Parts List
Reference
69-1612-xx 700-23731-xx Reflector top: center 1 Chapter 4
700-23734-xx Reflector top: top side 2 Chapter 4
700-23735-xx Reflector top: end 2 Chapter 4
700-23737-xx Light “cup” bracket 2 Chapter 4
700-23745-xx Plastic diffuser panel: center 1 Chapter 4
700-23746-xx Plastic diffuser panel: ends 2 Chapter 4
700-23747-xx Plastic diffuser panel: top right 1 Chapter 4
700-23748-xx Plastic diffuser panel: top left 1 Chapter 4
700-23826-xx Reflector bottom: center 1 Chapter 4
700-23827-xx Reflector bottom: left side top 2 Chapter 4
700-23828-xx Reflector bottom: left end 2 Chapter 4
700-23896-xx Metal trim panel: center right 1 Chapter 4
700-23897-xx Metal trim panel: top side 2 Chapter 4
700-23898-xx Metal trim panel: end 2 Chapter 4
700-24126-xx Metal trim panel: center left 1 Chapter 4
700-24152-xx Reflector bottom spacer 2 Chapter 4
700-27762-01 Reflector bottom: right side top 1 Chapter 4
700-27763-01 Reflector bottom: right end 1 Chapter 4
69-1619-xx 700-23749-xx Lighting support brackets 6 Chapter 4
700-23750-xx End structure brackets 4 Chapter 4
700-23899-xx L-brackets 4 Chapter 4
700-23752-xx Support struts 6 Chapter 4
700-25050-01 Diffuser Panel braces / H-clips 3 Chapter 4
69-1615-xx 48-2274-01 M8 x 70 mm screws 10 Chapter 4
