A-15
Cisco TelePresence System 3200
OL-14521-01
Appendix A Appendix A: Parts List Sorted by Carton
Carton 44 of 58: Lighting Assembly, 69-1613-xx, CTS3K-LIGHT-STR
Carton 44 of 58: Lighting Assembly, 69-1613-xx,
CTS3K-LIGHT-STR
Carton 45 of 58: Projector Bracket, 69-1631-xx,
CTS3K-STRUCTURE
Carton 46 of 58: Projector Screen, 74-5416-xx, CTS3K-SCREEN
Carton 47 of 44: Accessory Cabinet, Left, 69-1838-xx,
CTS3K-FUR-MAPLE
Kit ID Number
Sub-Kit ID
Number
Part Number Part Description Qty
Chapter Parts List
Reference
69-1613-xx 700-23756-xx Reflector transition piece: left 1 Chapter 4
700-23757-xx Reflector transition piece: right 1 Chapter 4
700-23758-xx Reflector transition piece: corner 1 Chapter 4
Kit ID Number
Sub-Kit ID
Number
Part Number Part Description Qty
Chapter Parts List
Reference
69-1631-xx 48-1963-01 M6 x 10 mm screws 4 Chapter 7
700-23824-xx Projector mounting bracket 1 Chapter 7
Kit ID Number
Sub-Kit ID
Number
Part Number Part Description Qty
Chapter Parts List
Reference
74-5416-xx Projector screen assembly 1 Chapter 7
1
1. Refer to the installation guide that is packaged with the assembly to install the projector screen.
Kit ID Number
Sub-Kit ID
Number
Part Number Part Description Qty
Chapter Parts List
Reference
69-1838-xx 700-29442-01 Accessory cabinet, left 1 Chapter 5, 6
