12-14
Cisco TelePresence System 3200
OL-14521-01
Chapter 12 Field-Replaceable Unit Guide
Replacing a Speaker—Part Number CTS-LDSPKR=
Step 18 Hang the speaker boards.
See Chapter 8, “Assembling the Remaining Cisco TelePresence Elements.”
Step 19 Power on the system by completing the steps in the “Powering On the System” section on page 12-4.
Step 20 Reattach the projector screen.
Tip The projector screen comes with printed instructions that should assist you with replacing it. If you
cannot find the instructions, reverse the order of removal to install it.
Step 21 Reassemble the left door tabletop section.
See Chapter 6, “Building the First Row Table Assembly.”
Step 22 Perform the display adjustment procedure.
See the “Setting Up the Displays” section on page 10-5 for more information.
Step 23 If you moved the camera, complete the following steps:
a. Perform the camera adjustment procedure and, if required, refocus and realign the camera.
See the “Setting Up the Cameras” section on page 10-6 for more information.
b. Attach the camera hood and lens hood.
See Chapter 8, “Assembling the Remaining Cisco TelePresence Elements.”
Step 24 Repackage the old display using the new display box and packing materials.
Replacing a Speaker—Part Number CTS-LDSPKR=
Required Information, Tools, and Equipment
To remove and replace a speaker for the Cisco TelePresence 3200, you need the following information,
tools, and equipment:
• Cisco TelePresence System Release 1.4 Administrator’s Guide, OL-13676-03
• Power screwdriver with 2.5, 3, and 6 mm (standard or round) Allen bits, or standard 2.5, 3, and 6 mm
Allen wrenches
Tip A round-head Allen bit allows the bit to work at an angle instead of only straight out, which is
helpful in tight spots.
• Manual screwdrivers, Phillips and flat head types
• Metric wrenches, 10 to 15 mm
• 9/64-inch Allen wrench (supplied with speakers)
• Laptop computer attached to network (for troubleshooting or reference)
