12-6
Cisco TelePresence System 3200
OL-14521-01
Chapter 12 Field-Replaceable Unit Guide
Replacing a Plasma Display—Part Number CTS-DISP-65-GEN4=
Caution Make sure all system power is turned off before beginning this disassembly.
Step 2 Remove the top camera hood by removing the screws that secure it to the bracket.
Step 3 Remove the lens hood by removing the two screws on the bottom of the hood.
Step 4 At the back of the camera cluster, disconnect the six cables: one Ethernet and one signal cable from each
of the three camera processors. As you remove each cable, attach a strip of temporary masking tape and
mark as “left,” “right,” or “center” for identification.
Tip To enable easier access to the loose cables, temporarily attach them to the upper back of the
display with masking tape.
Step 5 Remove the camera assembly by removing the screws from the top and side flanges of the camera
assembly support bracket. Retain the screws and set the assembly aside.
Step 6 Attach the new camera assembly to the mounting bracket using the same M8 screws that were removed.
See Chapter 8, “Assembling the Remaining Cisco TelePresence Elements” for more information.
Step 7 Reattach the Ethernet and signal cables according to your temporary markings.
Do not attach the camera hoods at this time.
Step 8 Power on the system by completing the steps in the “Powering On the System” section on page 12-4.
Step 9 Perform the camera adjustment procedure and, if required, refocus and realign the camera.
See the “Setting Up the Cameras” section on page 10-6 for more information.
Step 10 Re-attach the camera hood and lens hood.
Replacing a Plasma Display—Part Number
CTS-DISP-65-GEN4=
Required Information, Tools, and Equipment
To replace a display, you need the following information, tools, and equipment:
• Release Notes for Cisco TelePresence System, Release 1.4, OL-12074-05
• Cisco TelePresence System Release 1.4 Administrator’s Guide, OL-13676-03
Uncrating and unpacking:
• Claw hammer or small pry bar
• Large Phillips screwdriver
• * Tin snips
• * Pallet jack or hand cart (for moving components)
• * Safety gloves
