Cisco 3200 - Building the Display Shelf Assembly; Parts List

CHAPTER
4-1
Cisco TelePresence System 3200
OL-14521-01
4
Building the Display Shelf Assembly
Revised: September 16, 2009, OL-14521-01
Parts List
Display Shelf, Type 1
Key Part Description Part Number Qty Ctn Notes
1
Display shelf section: left 700-23600-xx 1 58
2
Display shelf section: center 700-23599-xx 1 58
3
Display shelf section: right 700-23598-xx 1 58
4
Not used
5
Left accessory cabinet attachment bracket 700-23336-xx 1 19
6
Right accessory cabinet attachment bracket 700-23337-xx 1 19
7
Not used
8
Connecting plates 700-23345-xx 2 13
9
Speaker board brackets 6 46 Included with projector screen kit.
10
Splines No part number 2 58
11
Draw bolts 51-4579-xx 6 58
12
and
13
M8 x 20 mm screws 48-2273-01 1
