Cisco 3200 - Building the Lighting Assembly

CHAPTER
5-1
Cisco TelePresence System 3200
OL-14521-01
5
Building the Lighting Assembly
Revised: September 16, 2009, OL-14521-01
Parts List
Key Part Description Part Number Qty Ctn Notes
1
Lighting support brackets 700-23749-xx 6 49
2
Support struts 700-23752-xx 6 49
3
End structure brackets 700-23750-xx 4 49
4
Plastic diffuser panel: center 700-23745-xx 1 49
5
Plastic diffuser panel: ends 700-23746-xx 2 49
6
Plastic diffuser panel: top right 700-23747-xx 1 49
7
Plastic diffuser panel: top left 700-23748-xx 1 49
8
L-bracket 700-23899-xx 4 49
9
Metal trim panel: center left 700-24126-xx 1 49
10
Metal trim panel: top side 700-23897-xx 2 49
11
Metal trim panel: end 700-23898-xx 2 49
12
Metal trim panel: center right 700-23896-xx 1 49
13
Reflector bottom tray: center 700-23826-xx 1 49
14
Reflector bottom tray: left side top 700-23827-02 1 49
15
Reflector bottom: left end 700-23828-02 1 49
16
Reflector bottom spacer 700-24152-xx 2 49
17
Reflector top: center 700-23731-xx 1 49
18
Reflector top: top side 700-23734-xx 2 49
19
Reflector top: end 700-23735-xx 2 49
20
Reflector transition piece: left 700-23756-xx 1 49
21
Reflector transition piece: right 700-23757-xx 1 49
22
Reflector transition piece: corner 700-23758-xx 2 49
