Cisco 3200 - Carton 13 of 58: Brackets, 69-1632-XX, CTS3 K-STRUCTURE

A-6
Cisco TelePresence System 3200
OL-14521-01
Appendix A Appendix A: Parts List Sorted by Carton
Carton 12 of 58: Camera Assembly Bracket, 69-1627-xx, CTS3K-STRUCTURE
Carton 12 of 58: Camera Assembly Bracket, 69-1627-xx,
CTS3K-STRUCTURE
Carton 13 of 58: Brackets, 69-1632-xx, CTS3K-STRUCTURE
Carton 14 of 58: Privacy Panel, Right Wing, 69-1628-xx,
CTS3K-STRUCTURE
Carton 15 of 58: Front Foot Stabilizer, 69-1624-xx,
CST3K-STRUCTURE
Kit ID Number
Sub-Kit ID
Number
Part Number Part Description Qty
Chapter Parts List
Reference
69-1627-xx 700-23346-xx Camera assembly bracket 1 Chapter 2
Kit ID Number
Sub-Kit ID
Number
Part Number Part Description Qty
Chapter Parts List
Reference
69-1632-xx 700-23338-xx Switch bracket, left
1
1. These brackets are for an optional Ethernet switch; if you did not order this option, disregard these parts.
1 Chapter 6
700-23342-xx Codec attachment brackets 6 Chapter 8
700-23344-xx Switch bracket, right
1
1 Chapter 6
700-23345-01 Connecting plates 10 Chapter 5, 6
700-23363-xx Display tilt bracket 6 Chapter 2
700-23426-xx Projector screen clips 4 Not used
700-23944-xx Speaker board brackets 12 Chapter 8
Kit ID Number
Sub-Kit ID
Number
Part Number Part Description Qty
Chapter Parts List
Reference
69-1628-xx 700-23362-xx Privacy panel: right wing 1 Chapter 6
Kit ID Number
Sub-Kit ID
Number
Part Number Part Description Qty
Chapter Parts List
Reference
69-1624-xx 700-23359-xx Front foot stabilizer 2 Chapter 2
