Chapter 12 Field-Replaceable Unit Guide
Replacing a Plasma Display—Part Number CTS-DISP-65-GEN4=
Step 1 Unscrew the left Accessory cabinet from the left Accessory cabinet attachment bracket. Remove the
Accessory cabinet from the work area.
Step 2 From the underside of the left Display shelf, unscrew one side of each metal plate connector.
Step 3 Loosen each draw bolt.
Step 4 Unscrew the left Display shelf from the two Display Shelf support brackets.
Step 5 Pull the left Display shelf away from the center Display shelf and set aside.
Step 6 If you are replacing the left Plasma display, skip to the next section, “Removing the Display Screen and
Completing the Procedure”.
Step 7 If you are replacing the center or right Plasma display, repeat Step 2 through Step 5 for the center display
shelf section.
Step 8 If you are replacing the center Plasma display, skip to the next section, “Removing the Display Screen
and Completing the Procedure”.
Step 9 If you are replacing the right Plasma display, unscrew the right Accessory cabinet from the right
Accessory cabinet.
Step 10 Place the Accessory cabinet under the right Tabletop wing segment to support it.
Step 11 Unscrew the right Tabletop wing segment from the Accessory cabinet attachment bracket.
Step 12 Unscrew the right Display shelf from the two Display Shelf support brackets. Set aside the Display shelf.
Removing the Display Screen and Completing the Procedure
Step 1 Detach the display screen’s signal cable from the correct codec unit.
See Chapter 9, “Routing Power and Signal Cables” for cable locations and reference.
Step 2 Detach the display screen’s power cable from the correct PDU.
See Chapter 9, “Routing Power and Signal Cables” for cable locations and reference.
Step 3 Remove the black tape from the seam behind and between the display screens.
Step 4 Remove the left and right Display tilt brackets from the Display shelf supports.
Step 5 Using a minimum of two people, lift the Plasma display straight up to disengage the hooks on the back
of the display from the horizontal mounting rod on the Display structure.
Step 6 Remove the display mounting bracket by removing six screws. Set the bracket aside for use with the
replacement display.
