A-19
Cisco TelePresence System 3200
OL-14521-01
Appendix A Appendix A: Parts List Sorted by Carton
Carton 54 of 58: Tabletop Leg Base, 69-1915-xx, CTS3K-STRUCTURE
Carton 54 of 58: Tabletop Leg Base, 69-1915-xx,
CTS3K-STRUCTURE
Carton 55 of 58: Lighting Assembly, 69-1613-xx,
CTS3K-LIGHT-STR
Carton 56 of 58: Projector Bracket, 69-1631-xx,
CTS3K-STRUCTURE
Carton 57 of 58: Foam Bumpers, 69-1634-xx, CTS3K-STRUCTURE
Kit ID Number
Sub-Kit ID
Number
Part Number Part Description Qty
Chapter Parts List
Reference
69-1620-xx 69-1636-xx 700-23305-01 I/O Module Cover plate 3 Chapter 7
800-28454-xx Tabletop leg base 3 Chapter 6
Kit ID Number
Sub-Kit ID
Number
Part Number Part Description Qty
Chapter Parts List
Reference
69-1613-xx 700-23756-xx Reflector transition piece: left 1 Chapter 4
700-23757-xx Reflector transition piece: right 1 Chapter 4
700-23758-xx Reflector transition piece: corner 1 Chapter 4
Kit ID Number
Sub-Kit ID
Number
Part Number Part Description Qty
Chapter Parts List
Reference
69-1631-xx 48-1963-01 M6 x 10 mm screws 4 Chapter 7
700-23824-xx Projector mounting bracket 1 Chapter 7
Kit ID Number
Sub-Kit ID
Number
Part Number Part Description Qty
Chapter Parts List
Reference
69-1634-xx 700-24275-xx Metal packaging brace 7 Chapter 6
800-28625-xx Molded foam bumper 7 Chapter 6
