Cisco 3200 - Page 138

8-2
Cisco TelePresence System 3200
OL-14521-01
Chapter 8 Assembling the Remaining Cisco TelePresence Elements
Parts List
Codec Assembly
1
Primary codec 800-30638-xx
CTS-CODEC-
PRI-G2
13
2
Secondary codec 68-2898-xx 2 5, 6,
40
3
Cable management bar 700-23449-xx 3 3, 5,
6, 40
4
Codec attachment brackets 700-23342-xx 6 13
5
M4 x 12 mm screws 48-1045-xx 20 1
6
M4 washers 49-0735-xx 20 1
Speaker Assembly
1
Speaker 74-4740-xx 3 8
2
Speaker boards left and right 74-5544-xx 2 58
3
Speaker board center 74-5307-xx 1 58
4
Speaker cable 37-0849-xx 3 1
5
Leveling foot 51-4540-xx 6 1
6
Speaker board knobs (MDF Fasteners) 6 46 Included with projector screen kit.
7
Speaker board feet 700-23944-xx 6 12
8
M8 x 20 mm screws 48-2273-xx 1
9
M8 washers 49-1165-xx 1
Cisco Unified IP Phone CP-7975G
CP-7975G-CTS
68-3309-xx
1 1 The IP Phone should be placed near
the right wing Table segment to
prevent it from appearing on screen.
Projector Screen Assembly, Type 1
800-28681-xx 1 46
Projector Screen Assembly, Type 2
CTS3K-SCREEN
74-5416-xx
1 46 Your system ships with either a Type
1 or Type 2 screen. Refer to the
projector screen installation guide
that is packaged with the assembly to
install the screen.
Audio/Video Extension Unit
1
Mounting bracket for audio/video
extension unit
700-26833-xx 1 1
2
audio/video extension unit 73-11609-02
800-30442-xx
11
Auxiliary Control Unit
1
Auxiliary Control Unit CTS-LIGHT-CTRL
69-1989-xx
122
Camera Target Assembly
1
Tabletop camera target: large 700-24323-xx 1 32
2
Tabletop camera target: small 700-24320-xx 1 32
3
Cardboard ruler 700-24321-xx 1 32
Key Part Description Part Number Qty Ctn Notes
