Chapter 8 Assembling the Remaining Cisco TelePresence Elements
Parts List
Step 8 Attach the Speaker board feet to the Speaker boards.
The feet should angle towards the rear of the Display structure.
Figure 8-8 Speaker Assembly
201178
7
5
9
8
3
2
