8-14
Cisco TelePresence System 3200
OL-14521-01
Chapter 8 Assembling the Remaining Cisco TelePresence Elements
Parts List
Step 11 Attach the Projector screen to the front of the system.
Note Refer to your Cisco TelePresence Projector Screen Assembly manual for the exact procedures
used to build and attach the projector screen. The Projector Screen Assembly manual is included
in the projector screen carton.
Figure 8-11 Projector Screen Assembly
