12-35
Cisco TelePresence System 3200
OL-14521-01
Chapter 12 Field-Replaceable Unit Guide
Replacing a Second Row Table Top Section
Step 28 Attach the privacy panel hangers to the table legs that support each side of the table top section.
See Chapter 7, “Building the Second Row Table Assembly” for the privacy panel support bracket
attachment points and screw locations.
Step 29 Attach the privacy panel alignment bracket.
See Chapter 7, “Building the Second Row Table Assembly” for the location of the privacy panel support
brackets.
Step 30 If you are replacing the left or right tabletop end, attach the privacy panel end pieces and panel end brace.
See Figure 7-47 for the privacy panel end piece locations and Figure 7-30 for the end brace locations.
Step 31 Insert the microphone cable into the hole in the table top and route the cable through the cable gutters
to the audio/video extension unit.
Step 32 Connect the microphone cable to the audio/video extension unit.
Step 33 Reconnect the microphone to the new table top section.
See Figure 7-38 for microphone installation instructions.
Step 34 Attach the privacy panels to the table sections.
Note If required, adjust the privacy panel sections so that there is an equal amount of space between
each section.
Step 35 If required, replace the cable cover for the right end privacy panel as shown in Figure 7-46 and add cable
ties to bundle the microphone cable with other cables.
Step 36 Reposition the second row table so that the trailing edge of the first row table is exactly 59 inches
(150 cm) behind the leading edge of the second row table. See Figure 7-48 for the correct second row
table positioning.
