5-15
Cisco TelePresence System 3200
OL-14521-01
Chapter 5 Building the Lighting Assembly
Parts List
Step 13 Attach the center Plastic Diffuser panel.
Figure 5-13 Center Plastic Diffuser panel
201137
4
31
