5-18
Cisco TelePresence System 3200
OL-14521-01
Chapter 5 Building the Lighting Assembly
Parts List
Step 16 Attach the two (vertical) Plastic Diffuser panels to the End Structure brackets.
Figure 5-16 Two (vertical) Plastic Diffuser panels
5
31
201140
3
