5-20
Cisco TelePresence System 3200
OL-14521-01
Chapter 5 Building the Lighting Assembly
Parts List
Step 18 Attach the center Reflector top to the center Reflector bottom.
Figure 5-18 Center Reflector top
Note Do not tighten screws until completing Step 22.
17
13
27
201141
