6-17
Cisco TelePresence System 3200
OL-14521-01
Chapter 6 Building the First Row Table Assembly
Parts List
Figure 6-15 Privacy Panel Assembly
Step 16 Attach the left Privacy panel.
2
5
Rotated
for clarity
201171
