6-19
Cisco TelePresence System 3200
OL-14521-01
Chapter 6 Building the First Row Table Assembly
Parts List
Figure 6-17 Privacy Panel Assembly
Step 18 Attach the right wing Privacy panel.
3
5
201173
Rotated
for clarity
