Cisco 7604 User Manual

12-11
Cisco 7600 Series Router Cisco IOS Software Configuration Guide, Release 12.2SX
OL-4266-08
Chapter 12 Configuring EtherChannels
Configuring EtherChannels
Router(config)#
This example shows how to verify the configuration:
Router# show lacp sys-id
23456,0050.3e8d.6400
Router#
The system priority is displayed first, followed by the MAC address of the router.
Configuring EtherChannel Load Balancing
To configure EtherChannel load balancing, perform this task:
The load-balancing keywords indicate the following information:
• dst-ip—Destination IP addresses
• dst-mac—Destination MAC addresses
• dst-port—Destination Layer 4 port
• mpls—Load balancing for MPLS packets
• src-dst-ip—Source and destination IP addresses
• src-dst-mac—Source and destination MAC addresses
• src-dst-port—Source and destination Layer 4 port
• src-ip—Source IP addresses
• src-mac—Source MAC addresses
• src-port—Source Layer 4 port
This example shows how to configure EtherChannel to use source and destination IP addresses:
Router# configure terminal
Router(config)# port-channel load-balance src-dst-ip
Router(config)# end
Router(config)#
This example shows how to verify the configuration:
Router# show etherchannel load-balance
Source XOR Destination IP address
Router#
Command Purpose
Step 1
Router(config)# port-channel load-balance
{src-mac | dst-mac | src-dst-mac | src-ip |
dst-ip | src-dst-ip | src-port | dst-port |
src-dst-port}
Configures EtherChannel load balancing.
Router(config)# no port-channel load-balance
Reverts to default EtherChannel load balancing.
Step 2
Router(config)# end
Exits configuration mode.
Step 3
Router# show etherchannel load-balance
Verifies the configuration.
