Chapter 28 Configuring IPv4 Multicast Layer 3 Switching
Configuring IPv4 Multicast Layer 3 Switching
Displaying IPv4 Multicast Layer 3 Switching Statistics
The show mls ip multicast command displays detailed information about IP multicast Layer 3
switching.
To display detailed IP multicast Layer 3 switching information, perform one of these tasks:
This example shows how to display information on a specific IP multicast Layer 3 switching entry:
Router# show mls ip multicast group 10.1.0.11
Multicast hardware switched flows:
Total shortcut installed: 0
This example shows how to display IP multicast group information:
Router# show mls ip multicast group 230.13.13.1 source 10.20.1.15
Multicast hardware switched flows:
(10.20.1.15, 230.13.13.1) Incoming interface:Gi4/8, Packets switched:0
Hardware switched outgoing interfaces:Gi4/9
RPF-MFD installed
Total hardware switched flows :1
Router#
This example shows how to display IP multicast Layer 3 switching information for VLAN 10:
Router# show mls ip multicast interface vlan 10
Multicast hardware switched flows:
(10.1.0.15, 224.2.2.15) Incoming interface: Vlan10, Packets switched: 0
Hardware switched outgoing interfaces:
MFD installed: Vlan10
(10.1.0.19, 224.2.2.19) Incoming interface: Vlan10, Packets switched: 1970
Hardware switched outgoing interfaces:
MFD installed: Vlan10
(10.1.0.11, 224.2.2.11) Incoming interface: Vlan10, Packets switched: 0
Hardware switched outgoing interfaces:
MFD installed: Vlan10
(10.1.0.10, 224.2.2.10) Incoming interface: Vlan10, Packets switched: 2744
Hardware switched outgoing interfaces:
MFD installed: Vlan10
Command Purpose
Router# show mls ip multicast group
ip_address
[interface
type slot/port
| statistics]
Displays IP multicast Layer 3 switching group information.
Router# show mls ip multicast interface {{vlan
vlan_ID
} | {
type
1
slot/port
} | {port-channel
number
}}
[statistics | summary]
1. type = ethernet, fastethernet, gigabitethernet, or tengigabitethernet
Displays IP multicast Layer 3 switching details for all
interfaces.
Router# show mls ip multicast source
ip_address
[interface {{vlan
vlan_ID
} | {
type
1
slot/port
} |
{port-channel
number
}} | statistics]
Displays IP multicast Layer 3 switching source information.
Router# show mls ip multicast summary
Displays a summary of IP multicast Layer 3 switching
information.
Router# show mls ip multicast statistics
Displays IP multicast Layer 3 switching statistics.
