52-8
Cisco 7600 Series Router Cisco IOS Software Configuration Guide, Release 12.2SX
OL-4266-08
Chapter 52 Configuring Local SPAN, RSPAN, and ERSPAN
Local SPAN, RSPAN, and ERSPAN Configuration Guidelines and Restrictions
Note IP multicast switching using egress packet replication is not compatible with SPAN. In some cases,
egress replication can result in multicast packets not being sent to the SPAN destination port. If you are
using SPAN and your switching modules are capable of egress replication, enter the mls ip multicast
replication-mode ingress command to force ingress replication.
Local SPAN, RSPAN, and ERSPAN Session Limits
These sections describe the local SPAN, RSPAN, and ERSPAN session limits:
PFC3, page 52-8
PFC2, page 52-9
PFC3
These are the PFC3 local SPAN, RSPAN, and ERSPAN session limits:
These are the PFC3 local SPAN, RSPAN, and ERSPAN source and destination limits:
Total Sessions
Local SPAN, RSPAN Source, or ERSPAN Source
Sessions
RSPAN Destination
Sessions
ERSPAN Destination
Sessions
66 2 (ingress or egress or both) 64 23
In Each Local
SPAN Session
In Each RSPAN
Source Session
In Each ERSPAN
Source Session
In Each RSPAN
Destination
Session
In Each ERSPAN
Destination
Session
Egress or “both” sources
With releases earlier than
Release 12.2(18)SXE
11 1
Release 12.2(18)SXE and
later releases
128 128 128
Ingress sources
With releases earlier than
Release 12.2(18)SXD
64 64 64
Release 12.2(18)SXD
and later releases
128 128 128
RSPAN and ERSPAN
destination session sources
———1 RSPAN VLAN1 IP address
Destinations per session 64 1 RSPAN VLAN 1 IP address 64 64
