22-8
Cisco 7600 Series Router Cisco IOS Software Configuration Guide, Release 12.2SX
OL-4266-08
Chapter 22 Configuring Layer 3 Interfaces
Configuring IPX Routing and Network Numbers
This example uses the show running-config command to display the interface IPv4 address
configuration of Fast Ethernet port 5/4:
Router# show running-config interfaces fastethernet 5/4
Building configuration...
Current configuration:
!
interface FastEthernet5/4
description "Router port"
ip address 172.20.52.106 255.255.255.248
no ip directed-broadcast
!
Configuring IPX Routing and Network Numbers
Note The MSFC supports IPX with fast switching.
For complete information and procedures, refer to these publications:
• Cisco IOS AppleTalk and Novell IPX Configuration Guide, Release 12.2, at this URL:
http://www.cisco.com/en/US/docs/ios/12_2/atipx/configuration/guide/fatipx_c.html
• Cisco IOS AppleTalk and Novell IPX Command Reference, Release 12.2, at this URL:
http://www.cisco.com/en/US/docs/ios/12_2/atipx/command/reference/fatipx_r.html
To configure routing for Internetwork Packet Exchange (IPX) and configure IPX on a Layer 3 interface,
perform this task:
Command Purpose
Step 1
Router(config)# ipx routing
Enables IPX routing.
Step 2
Router(config)# router ipx_routing_protocol
Specifies an IP routing protocol. This step might include
other commands, such as specifying the networks to route
with the network command.
Step 3
Router(config)# interface {vlan vlan_ID } |
{
type
1
slot/port } | {port-channel
port_channel_number }
Selects an interface to configure.
Step 4
Router(config-if)# ipx network [network |
unnumbered] encapsulation
encapsulation_type
Configures the IPX network number. This enables IPX
routing on the interface. When you enable IPX routing on
the interface, you can also specify an encapsulation type.
Step 5
Router(config-if)# no shutdown
Enables the interface.
Step 6
Router(config-if)# end
Exits configuration mode.
Step 7
Router# show interfaces [{vlan vlan_ID } |
{
type
1
slot/port } | {port-channel
port_channel_number }]
Router# show ipx interfaces [{vlan
vlan_ID } |
{
type
1
slot/port } | {port-channel
port_channel_number }]
Router# show running-config interfaces [{vlan
vlan_ID } | { type
1
slot/port } | {port-channel
port_channel_number }]
Verifies the configuration.
