15-16
Cisco 7600 Series Router Cisco IOS Software Configuration Guide, Release 12.2SX
OL-4266-08
Chapter 15 Configuring Private VLANs
Configuring Private VLANs
When you configure a Layer 2 interface as a private VLAN promiscuous port, note the following
information:
• The secondary_vlan_list parameter cannot contain spaces. It can contain multiple comma-separated
items. Each item can be a single private VLAN ID or a hyphenated range of private VLAN IDs.
• Enter a secondary_vlan_list value or use the add keyword with a secondary_vlan_list value to map
the secondary VLANs to the private VLAN promiscuous port.
• Use the remove keyword with a secondary_vlan_list value to clear the mapping between secondary
VLANs and the private VLAN promiscuous port.
This example shows how to configure interface FastEthernet 5/2 as a private VLAN promiscuous port
and map it to a private VLAN:
Router# configure terminal
Router(config)# interface fastethernet 5/2
Router(config-if)# switchport mode private-vlan promiscuous
Router(config-if)# switchport private-vlan mapping 202 303,440
Router(config-if)# end
This example shows how to verify the configuration:
Router# show interfaces fastethernet 5/2 switchport
Name: Fa5/2
Switchport: Enabled
Administrative Mode: private-vlan promiscuous
Operational Mode: down
Administrative Trunking Encapsulation: negotiate
Negotiation of Trunking: On
Access Mode VLAN: 1 (default)
Trunking Native Mode VLAN: 1 (default)
Administrative private-vlan host-association: none ((Inactive))
Administrative private-vlan mapping: 202 (VLAN0202) 303 (VLAN0303) 440 (VLAN0440)
Operational private-vlan: none
Trunking VLANs Enabled: ALL
Pruning VLANs Enabled: 2-1001
Capture Mode Disabled
Step 3
Router(config-if)# switchport mode private-vlan
{host | promiscuous}
Configures the Layer 2 port as a private VLAN
promiscuous port.
Router(config-if)# no switchport mode
private-vlan
Clears the private VLAN port configuration.
Step 4
Router(config-if)# switchport private-vlan
mapping
primary_vlan_ID
{
secondary_vlan_list
|
add
secondary_vlan_list
| remove
secondary_vlan_list
}
Maps the private VLAN promiscuous port to a primary
VLAN and to selected secondary VLANs.
Router(config-if)# no switchport private-vlan
mapping
Clears all mapping between the private VLAN
promiscuous port and the primary VLAN and any
secondary VLANs.
Step 5
Router(config-if)# end
Exits configuration mode.
Step 6
Router# show interfaces [
type
1
slot/port
]
switchport
Verifies the configuration.
1. type = ethernet, fastethernet, gigabitethernet, or tengigabitethernet
Command Purpose
