Chapter 41 Configuring PFC QoS
Understanding How PFC QoS Works
WS-X6748-GE-TX with DFC3 2q8t WRR 1p3q8t DWRR 1.3 MB 166 KB 1.2 MB
WS-X6748-GE-TX with CFC 1q8t —
WS-X6748-SFP with DFC3 2q8t WRR
WS-X6748-SFP with CFC 1q8t —
WS-X6724-SFP with DFC3 2q8t WRR
WS-X6724-SFP with CFC 1q8t —
WS-X6548-GE-TX 1q2t — 1p2q2t WRR 1.4 MB 185 KB 1.2 MB
WS-X6548V-GE-TX
WS-X6548-GE-45AF
WS-X6516-GBIC 1p1q4t — 1p2q2t WRR 512 KB 73 KB 439 KB
WS-X6516A-GBIC WRR 1 MB 135 KB 946 KB
WS-X6516-GE-TX WRR 512 KB 73 KB 439 KB
WS-X6408-GBIC 1q4t — 2q2t WRR 80 KB 432 KB
WS-X6408A-GBIC 1p1q4t — 1p2q2t WRR 73 KB 439 KB
WS-X6416-GBIC
WS-X6416-GE-MT
WS-X6316-GE-TX
WS-X6148-GE-TX 1q2t — 1.4 MB 185 KB 1.2 MB
WS-X6148V-GE-TX
WS-X6148-GE-45AF
WS-X6148A-GE-TX
1p3q8t
DWRR
5.5 MB
120 KB
5.4 MB
WS-X6148A-GE-45AF
Table 41-5 10 Gigabit Ethernet Modules
Modules
Ingress
Queue and
Drop
Thresholds
Ingress
Queue
Scheduler
Egress
Queue and
Drop
Thresholds
Egress
Queue
Scheduler
Total Buffer
Size
Ingress
Buffer Size
Egress
Buffer Size
WS-X6708-10GE 8q4t DWRR 1p7q4t DWRR
SRR
200 MB 108 MB 90 MB
WS-X6704-10GE with DFC3 8q8t WRR 1p7q8t DWRR 16 MB 2 MB 14 MB
WS-X6704-10GE with CFC 1q8t —
WS-X6502-10GE 1p1q8t — 1p2q1t DWRR 64.2 MB 256 KB 64 MB
WS-X6501-10GEX4
Table 41-4 Gigabit and 10/100/1000 Ethernet Modules
Modules
Ingress
Queue and
Drop
Thresholds
Ingress
Queue
Scheduler
Egress
Queue and
Drop
Thresholds
Egress
Queue
Scheduler
Total Buffer
Size
Ingress
Buffer Size
Egress
Buffer Size
